Victron Quattro 48/5000/70-100/100 120V VE.Bus

The Victron Quattro adds a second AC input with a fully integrated transfer switch to the standard MultiPlus feature set — ideal for systems that need to automatically switch between two AC sources, such as shore power and a generator, or grid and generator backup. PowerAssist boosts a limited AC source with battery power during high loads, and if both AC sources fail, the inverter takes over instantly to keep connected loads running.

Key Specs:

• DC Input: 38-66V (48V system)
• Continuous Output: 5000 VA
• Peak Power: 10000W
• AC Output: 120V ± 2%, 60Hz ± 0.1%
• Max Charge Current: 70A
• AC Inputs: Two, each rated 100A, with integrated automatic transfer switch
• Efficiency: up to 94%
• Lithium Battery Compatible: Yes

Pairs with a GX device (like the Cerbo GX) for full remote monitoring and control via the free VRM app — check system status or reconfigure settings from anywhere.
